Description
- High thermal sensitivity, NETD < 20mK
- Fast 50Hz imaging
- Built-in laser rangefinder
- Adjustable color palettes
- High resolution OLED display
- Various reticle types and colors
- On-board video/audio recording and image capture
- Wi-Fi data transmission
- More than 6 hours battery life
- Waterproof & shockproof
The AGM GLOBAL VISION Secutor LRF Thermal Imaging Riflescope was built to expand and diversify the line of rangefinder equipped thermal riflescopes in the AGM assortment. Though the Secutor LRF series will utilize the same upgraded thermal sensors that can be found across the majority of AGM's new products, the three primary differences include an upgraded 1000m laser rangefinder, a digital compass and utilization of a CR123A based power system. These differences, while primarily aimed at more noncommercial tactical applications, still offer both extended ranging and battery familiarity to commercial predator hunters as well.
The extended range of the LRF, when paired with the non-proprietary CR123A power system, helps make the Secutor LRF's a great option for different law enforcement and defense applications. Meanwhile, the integrated compass gives shooters an added layer of situational and positional awareness. The newly introduced sub-20 milikelvin thermal sensors will aid users in these tactical scenarios by increasing their ranging capabilities, as well as increase their ability to both detect and identify targets at longer distances. With both 50 and 75mm options, the Secutor LRF’s provide more authenticity than ever to the phrase: long range.
Warranty Information
Palettes | Black Hot, White Hot, Red Hot, Fusion |
Exit Pupil Diameter | 6 mm |
Reticle | 10 types, 4 colors, on/off |
Boresight Adjustment | Digital Controlled |
Picture In Picture Mode (PIP) | Yes |
Video Recording | Yes |
Audio Recording | Yes |
Magnification | 3x - 24x |
Detector type | 12µm VOx Uncooled Focal Plane Array |
Response Waveband | 8µm to 14µm |
FFC (Flat Field Correction) | Auto, Manual, External Correction |
Highest Temperature Spot Tracking | Yes |
Standby Mode | Yes |
Refresh rate | 50 Hz |
Resolution | 384 x 288 |
Detection Range (6' object) | 1,800 m/yd |
Lens system | 35 mm; F1.0 |
NETD | Less than 20 mK (@25°C), F#=1.0 |
Protection level | IP67 |
Field of View (H x X), deg | 7.5° x 5.6° |
Digital Zoom | 1x, 2x, 4x, 8x |
Diopter adjustment range | -5 to +3 dpt |
Monitor | 1024x768, 0.39 inch, OLED |
Eye relief | 45 mm |
Storage | 16 GB EMMC |
Capture Snapshot | Yes |
Battery Type | Four 123A Lithium batteries |
Wi-Fi | Yes |
Battery Operating Time | ?ore than 7 hours |
External power supply | 5 VDC/2 A, USB Type-C |
Operating Temperature Range | -30°C to 55°C (-22°F to 131°F) |
Dimensions | 215 x 101 x 74 mm (8.5 x 4.0 x 2.9 in) (w/o mount) |
Weight | 0.6 kg (1.32 lb) |
