Description
- Can be used with all Aimpoint sights for long-range aiming or observation
- Variable (-2 to +2) dioptric setting
- Can also be used as a handheld 3x monocular
- Encased in a shock absorbing protective rubber cover
- 3X-C Magnifier only - NO MOUNT INCLUDED
The AIMPOINT 3X-C Magnifier (200273) offers 3X magnification and incorporates proven design features and premium Aimpoint quality at an entry level price point. It can be used with all Aimpoint sights for long-range aiming or observation. A variable (-2 to +2) dioptric setting allows this magnifier to be adapted to the individual shooter's eye.
The 3X-C can also be used as a handheld 3X monocular. Aimpoint magnifiers utilize the red dot in Aimpoint sights as the aiming reticle, eliminating the need for re-zeroing when shifting between non-magnified and magnified aiming.
The 3X-C is encased in a shock absorbing protective rubber cover that also creates an ideal ergonomic grip. Internal optical adjustments make aligning the magnifier and sight quick and easy.
Warranty Information
Optical Specifications | |
Optical Magnification | 3x |
Aiming Dot Size | None, uses the reticle / red dot in the Aimpoint sight |
NVD Compatible | Yes |
Field of View, deg | 6° |
Exit Pupil, mm | 6.5 |
Eye Relief, mm | 56 |
Dioptric Adjustment | ± 2.0 D |
Physical Specifications | |
Length Sight Only, in | 4" |
Width Sight Only, in | 1.8" |
Height Sight Only, in | 1.8" |
Weight Sight Only (Including Battery), oz | 7.8 including rubber cover |
Environmental Specifications | |
Temperature Range Operation | -45 °C to +71 °C (-49 °F to +160 °F) |
Temperature Range Storage | Operable after a temperature shock between -45 °C and +71 °C. -40 °C and +55 °C (-40 °F and +131 °F) |
Temperature Shock | From -25 °C to +40 °C |
Humidity | Operable during and after Humidity. Limits: RH: 95%, Temp: +20 °C to +50 °C (+68 °F to +122 °F), cyclic |
Submersible | To a depth of 0.5 m (2 ft.) |
Shock | Withstands shock. Limits: X-axis: 500 g, 0.7 – 1.1 ms (3 shocks), Y-axis: 40g ±4g, 11 ±1ms (2 shocks in each direction, Z-axis: 40g ±4g, 11 ±1ms (2 shocks in each direction) |
Vibration | Withstands Vibration. Limits: Vibration, sinusoidal in a frequency range of 10-150 Hz. Frequency: 10-30 Hz, ±1.587 mm, Frequency: 30-150 Hz. 5.75 g, 1 octave/min. Direction: X, Y and Z, Time: 30 min/direction |
