- Compatible with every generation of NVD
- ACET technology allows up to 80,000 hours (over 8 years) of daytime operation on one AA battery
- Internal voltage regulator allows the CompM4 to be used with any AA size battery
- 7 NVD settings and 9 daylight settings
- QRP2 mount has twice the clamping force of the original QRP, and the mounting knob is wider and shorter to improve operation and lower the risk of snagging on other gear
- 500,000 hours of use on NVD setting
- 2 MOA dot for close combat and long distance engagement
- Matches perfectly with Aimpoint 3xMag
- Submersible to 150 feet (45 meters)
- Mechanical switch for speed and reliability
The AIMPOINT CompM4s Red Dot Sight w/ QRP2 Mount (12172) is the finest sight that Aimpoint has ever produced. Improvements include improved energy efficiency that provides up to 8 years of continuous use from a single AA battery. The CompM4s sight incorporates an integral mount that eliminates the need for a separate ring, and can be customized with vertical and forward spacers to fit a variety of weapon systems. The CompM4 series of sights are available in two versions: the CompM4 offers a high battery compartment, while the CompM4s offers a low battery compartment.
The performance of the CompM4s series of sights is optimized for use with all generations of night vision devices (NVDs), but is especially suited for 3rd generation night vision technology.
Aimpoint's unique band-pass coating on the front lens reflects select frequencies of red light at near 100% efficiency in order to give the highest possible dot brightness with the smallest amount of energy while transmitting nearly 100% of light in the Infrared and near-infrared part of the spectrum to provide the clearest, brightest image possible when used with a 3rd generation NVD.
With 7 NVD-compatible brightness settings and 9 Daylight settings including one extra-bright setting, the CompM4s Red Dot Sight is ready for use around the clock.
Videos
View AllClose
Warranty Information
Optical Data |
|
| Magnification | 1x |
| Clear aperture, mm | 26 |
| Eye relief | Unlimited |
| Operating principle | Reflex Collimator sight with LED |
| Aiming dot size | 2 MOA |
| Dot intensity | Visible against a background luminance of 0,1 to 55 000 lx |
| Optical signature | No optical signature is visible at 10 meter distance, front side, on appropriate settings with NVD 3 |
| Dot color | Peak Wavelength: 650 ± 10 nm |
| NVD compatible | Yes |
| Optical coating | Anti-reflex, all surfaces and multi-layer NVD-Compatible 1, 2, 3 |
Power Source |
|
| Battery type | AA size battery, (rechargeable 1.2V), alkaline/lithium 1,5V or ithium 3-3,7V (acceptable voltage 1,2-5volt) |
| Battery life | 80.000 h continuous (pos. 12 of 16) Responds to >500 000 hours at NVD setting (pos. 4) |
| Power intensity | 7 NVD and 9 Daylight, of which 1 extra bright |
Physical Specifications |
|
| Length sight only, mm/in | 120 / 4-3/4" |
| Length conf., mm/in | 135 / 5-5/16" |
| Width, mm/in | 72 / 2-13/16" |
| Height sight only, mm/in | 60 / 2-3/8" |
| Height conf., mm/in | 72 / 2-13/16" |
| Weight sight only (incl. battery), g/oz | 268 / 9,4 |
| Weight conf., g/oz | 376 / 13,2 incl. Lens Covers, Kill-Flash, Mount, and Spacer |
| Housing material | High Strength Aluminum |
| Housing finish and color | Matte Black |
| Housing anodized | Yes |
| Height of optical axis - sight and mount, mm/in | 30 / 1-3/16" over top surface of Picatinny/Weaver Rail |
| Height of optical axis - sight, mount and Micro spacer XX, mm/in | 39 / 1-9/16" over top surface of Picatinny/Weaver Rail |
| Adjustment | Range ±2 m at 100 meters (±2 yds at 100 yds) in windage and elevation, 1 click = 16 mm at 100 meters = 13 mm at 80 meters = 9/16" at 80 yds |
