ASK AN EXPERTDescription
- Compatible with Picatinny or Weaver scope rings
- Mounting hardware included
- Available in Hardcoat black finish
- Solid 7075 T6 Aircraft Grade Aluminum
This base is Right-Handed only.
It is available in 3/8" and 11mm dovetails. Determine which dovetail you have by measuring across the top of the dovetail. If you measure 0.437" you have an 11mm dovetail. If you measure 0.5" you have a 3/8" dovetail.
Picatinny cross slots run the full length of the rail, which gives the shooter flexibility when mounting scope rings and other accessories. These one-piece scope mounts are the obvious choice for hunters and tactical shooters alike.
This mount is a Picatinny-style base and compatible with Picatinny or Weaver scope rings.
After machining, the mounts are tumbled, sand blasted, and Type III anodized for long lasting durability.
We recommend:
0 MOA - if shooting 0-150 yards
20 MOA - if shooting 150-300 yards
Warranty Information
| Rail Type | One Piece Picatinny |
| Machined From | Solid 7075 T6 Aircraft Grade Aluminum |
| Finish | Matte Black Hardcoat |
| Center Spread, in | 4.169" |
| Overall Length, in | 5.575" |
| Height, in | .540" (Top of Receiver to Top of Picatinny) |
| Quick Disconnect Ring Compatible | Yes |
| Torque Specs | 25 in/lbs |
| Mounting Hardware | #6-32 X 3/4 Screws and T-15 Bit Included |
| Dovetail | 11mm (measures .437" across top of dovetail) |
| Weight | 2.5 oz. |
