- Adjustable Taper Crimp Dies: Redding's Micro-Adjustable Taper Crimp Dies are top adjusting to simplify making precise adjustments; variations in case length and wall thickness both adversely effect proper adjustment
- High-Quality Steel Crimp Dies: The Redding Micro-Adjustable Taper Steel Crimp Dies have a knurled micrometer type barrel situated on the top of the die for easy access and provides approximately +/- .100 of "on-the-fly" adjustment after initial setup
- Internal Crimping Sleeve: Versatility is enhanced by the internal crimping sleeve which can be reversed to accommodate two different cartridges having closely related body diameters; an example is the .38 Super and the 9mm family of cartridges
- Maximum Performance: The die body thru holes are machined to very tight tolerances providing a close fitting lead into the die for a maximum retention of finished round concentricity; no more guessing if your crimp is at the right place
- Durable & Tight: Taper crimp dies were designed for handgun cartridges which headspace on the case mouth in which conventional roll crimping is undesirable; a taper crimp gently tapers tighter and tighter to hold the bullet in place
The REDDING .223 Rem Micrometer Adjustable Crimping Die is top adjusting to simplify making precise adjustments because any variation in case length and wall thickness both adversely affect proper adjustment.
Traditional Taper Crimp Die adjustment is both time consuming and imprecise due to the coarse 7/8 - 14 pitch die threads and the need to re-position the lock ring, this is especially important to users of progressive reloading presses with tight space constraints.
The new Micrometer Adjustable Crimping Dies have a knurled micrometer barrel situated on the top of the die for easy access and provides approximately +/- .100" of "on-the-fly" adjustment in .001" increments.
Versatility is enhanced on handgun dies by being able to reverse the internal crimping sleeve to accommodate two different cartridges having closely related body diameters. An example is the 38 Super and the 9mm family of cartridges. Rifle cartridges are non-reversible.
