ASK AN EXPERTDescription
- Superior for hogs, coyote and predator control at medium- and long-range distances
- High resolution 1024x768 OLED Display
- Excellent performer in high humidity conditions
- Mountable in front of scopes with lens diameters ranging from 24mm to 64mm
- Optimal with 2.0x to 18.0x day time scopes
- Convertible to the 4.0x - 16.0x hand held Thermal scanner when coupled with a detachable eye piece
- Manual control of the image sharpness and screen brightness
- Ability to center the screen with respect to the viewed reticle
- Ability to save zeroing data of 4 gun profiles
- Rugged, compact and lightweight
Boasting an advanced 12μm Vanadium Oxide (VOx) 640x480 resolution and proprietary electronics, the BERING OPTICS Super Yoter C Dedicated Thermal Clip-On Scope on has no equal. It features a superior 50mm Germanium Lens, designed with predator control in mind for medium to far distances. The product is lightweight and compact, made for the coyote and predator hunting market. The product can also be outfitted with a Quick Release Weaver Mount (SKU# 80990), enabling it to be used with conventional tactical sights such as prismatics.
The Super Yoter C offers a comprehensive menu, easy navigation, plus features such as switchable image polarity memory for 4 gun profiles. Its tactile control buttons are ideal for pitch black operation. Plus, it's nitrogen purged, waterproof, dustproof, and shockproof for .338 Win Mag, .30-06 Sprg, .300 H&H and other magnum calibers. Moreover, it excels in action-ready scenarios under various lighting conditions and environmental obscurants such as dust, haze, fog, and high humidity.
Warranty Information
| Optical Magnification in the Clip-on mode, x | 1.0x |
| Digital Multiplication, X | 1X, 2X, 4X |
| Optical Magnification in the Thermal Viewer mode, x | 4.0x, 8.0x, 16.0x |
| Objective Lens system | 50mmF/1.0 |
| Angular FOV at 1.0x (horizontal x vertical), degree | 8.8° x 7.0° |
| Eye relief, mm (hand held mode / clip-on mode) | 20/30 |
| Exit Pupil, mm (hand held mode / clip-on mode) | 6/25 |
| Focus range, approx., yds / m | 2 / 1.85 to infinity |
| Diopter Adjustment, D (hand held mode only) | -5/+5 |
| Core resolution, pxl | 640x480 |
| Pixel pitch, μm | 12 |
| Image refresh rate, Hz | 50 |
| Thermal Sensitivity (NETD), mK | ≤50 |
| Display type and resolution, pxl | OLED 1024x768 |
| Start-up time, min., sec. | 5 |
| Object type and size, approx., ft² / m² | 8/0.75 25.8/2.4 |
| Detection, approx.*, yds / m | 2500/2290 2200/3000 |
| Recognition, approx., yds / m | 450/400 800/730 |
| Identification, approx., yds / m | 250/230 550/500 |
| Dimensions w/out adaptor, in / mm (hand held mode / clip-on mode) | 6.61" x 2.72" x 2.95" / 16 8x 69 x 75 7.10" x 2.72" x 2.95" / 180 x 69 x 75 |
| Weight, approx., oz/g (hand held mode / clip-on mode) | 15.6/442 18.4/522 |
| Power supply standard | CR123 (two) |
| Estimated battery life, hour | up to 4 |
| Operating temperature, °F/°? | -44° to +122° / -20° to +50° |
| Water intrusion | IP66 |
| Humidity, % | Up to 98% |
