- Patented Exposed Zero Lock 'n' Stop elevation turret
- First Focal Plane (FFP)
- 30mm Mono-tube chassis
- Side Focus
- Illumination
- Wide Angle FOV
- High volume eyebox
- 100mm eye relief
- Multi-LED high intensity reticle
- High grade, low dispersion Crown glass
All models feature Hawke's H7 optics with high zoom ratio, supreme clarity and light transmission.
FFP MOA Hunter (25x)
The FFP MOA HUNTER reticle was developed specifically for first focal plane optical systems and based around the common principles of MOA spaced reticles. The bright center dot gives a sharp aim point for quick reference and target acquisition. The FFP MOA HUNTER has aim points every 2 MOA for holdover and windage and uses a hollow outer post design to keep more of the target visible while aiming.
RETICLE SUBTENSIONS
The MOA spaced reticle and 1/4 MOA turrets make for easy point of aim adjustment. Every 4 clicks on the turret will measure exactly 1 MOA spacing on the reticle. Because of FFP this is true on all magnifications.
Warranty Information
| Objective Lens | 56mm |
| Reticle | FFP MOA Hunter (25x) |
| Parallax | Side Focus |
| Magnification | 5 - 25x |
| Optical System | System H7 |
| Scope Tube | 30mm |
| Illumination | 6 Levels with Off Positions In-between - Red |
| Field of View | 22.5 - 4.5ft @100yds |
| Field of View, deg | 4.3 - 0.9° |
| Eye Relief | 4in |
| PX/Focus | 15yds - infinity |
| Turret Type | Zero Lock 'n' Stop |
| Click Value | 1/4 MOA |
| Elevation Turret Clicks (max) | 65 MOA |
| Windage Turret Clicks (max) | 65 MOA |
| Exit Pupil | 0.44 - 0.09" |
| Ocular Type | Locking Fast Focus |
| Power Selector | Knurled Posi-Grip with Removable Zoom Lever |
| Lens Coating | Fully Multi-Coated - 21 Layers |
| Focal Plane | FFP (First Focal Plane) |
| Length, in | 14.4in |
| Weight | 24.6oz |
