ASK AN EXPERTDescription
- 3.6x-18x magnification
- 5:1 Zoom Ratio: Gives you 5 times more magnification at high power than at low power
- Leupold's Custom Dial System (CDS) gives you the ability to customize your turret (adjustment dial)
- Zero Lock Dial - The ZeroLock system eliminates accidental dial movement by locking it in place
- The ZeroStop system creates a backstop when returning the dial back to zero
- Lightweight Aluminum Housing - Aluminum offers excellent durability and ruggedness without adding unnecessary weight
- M5C3 ZeroLock Adjustments - Provide up to 30-MILs of adjustment in 3 revolutions and 0.1 MIL clicks
- The ZeroLock feature prevents inadvertent adjustments and ensures accurate return to zero
- Motion Sensor Technology (MST) extends battery life by automatically deactivating illuminated reticles after five minutes of inactivity and then reactivates instantly as soon as movement is detected
- The side focus adjusts the scope's parallax, making the reticle clearer and have less perceived movement when you're shooting at different distances
Pick up a Leupold Mark 5HD 3.6-18x44mm 35mm M5C3 Riflescope and you'll feel the difference. It's up to 20 ounces lighter than other riflescopes in its class, giving you an advantage in the field or at the range. The versatile 3.6-18x magnification range helps you engage close targets, while also giving you the flexibility to reach out to long distances. With three revolutions of elevation adjustment and multiple reticle options, this scope will max out the performance of the latest long-range rifles and ammunition, guaranteed.
Built around Leupold's Professional-Grade Optical System, the Mark 5HD offers unmatched light transmission that's designed to outperform in the most challenging lighting conditions. Its industry leading glare reduction provides a clear image in harsh, direct light, while the resolution and clarity will meet the demands of any professional guide or shooter. Ergonomically designed with more tactile and audible click adjustments, larger numbers, and a high-speed throw lever, the Mark 5HD is built to put accurate fire downrange faster.
The unique combination of features, durability, and professional-grade optical performance guarantees that the Mark 5HD can handle any challenge you throw at it. It's 100% waterproof and fogproof, and like all Leupold riflescopes, it's designed, machined, and assembled in the USA and guaranteed to perform for life.
Warranty Information
| Magnification | 3.6x-18x |
| Objective Lens Diameter, mm | 44 |
| Field of View (FOV) @ 100yds, ft | 28.3' (Low) - 5.8' (High) |
| Angular FOV, deg | 5.4° (Low) - 1.1° (High) |
| Eye Relief, in | 3.5" (Low) - 3.8" (High) |
| Tube Diameter, mm | 35 |
| Value per Click | 0.1 Mil |
| Elevation Adjustment Range | 100 MOA |
| Windage Adjustment Range | 80 MOA |
| Elevation Adjustment Range | 29 MIL |
| Windage Adjustment Range | 23 MIL |
| Elevation Adjustment Range, cm @ 100m | 291 |
| Windage Adjustment Range, cm @ 100m | 233 |
| Elevation Adjustment Per Revolution | 10.5 MIL |
| Windage Adjustment Per Revolution | 10 MIL |
| Elevation Dial Travel Limit | 30 MIL |
| Minimum Parallax-Free Distance, yd | 50 |
| Windage Adjustment Type | Capped |
| Elevation Adjustment Type | M5C3 |
| Magnification Type | Variable |
| Reticle Focal Plane | First Focal Plane |
| Reticle | Illum. FFP PR1-MIL |
| Reticle Type | Illuminated |
| Number of Illum Settings | 7 |
| Finish | Matte |
| Rezero Type | Set Screw |
| Locking Dial | Yes |
| Revolution Indicator | Yes |
| Adjustable Objective | No |
| Custom Dial System (CDS) | No |
| BDC Dial Included | No |
| Daylight Bright Illumination | No |
| Electronic Reticle Level | No |
| Guard-ion Lens Coating | No |
| Switch Type | Dial |
| Battery Type | CR2032 |
| Battery Life, hrs | 1800 - Low Intensity, 96 - High Intensity |
| Total Length, in | 12.1" |
| Eyepiece Length, in | 3.3" |
| Weight, oz | 26 |
