- 20-60x magnification eyepiece
- Angled viewing
- Apochromatic HD fluoride glass elements
- Swarodur/Swarotop High-Contrast Coatings
- Lightweight aluminum housing
- Rubber-armored exterior
- Integrated tripod collar
- Water and fogproof construction
With its angled view the ATS-80 Spotting Scope enables comfortable observation for hours. The 80mm objective lens diameter provides higher detail recognition, while a wider exit pupil ensures brighter images and comfortable viewing even in poor lighting conditions.
Anyone looking for equipment of proven quality right from the start will be delighted by the spotting scopes in the ATS/STS range. They offer all the features that you would look for in a spotting scope, including a large field of view for rapid target acquisition and tried-and-tested optics. The (straight or angled) view can be adjusted to meet personal preferences for any hunting situation.
Warranty Information
| Magnification | 20-60x |
| Objective Lens Diameter, mm | 80 |
| Field of View (FOV) @ 1000yds, ft | 108-60 |
| Field of View, deg | 65°-40° (Apparent) 2.1°-1.1° (Actual) |
| Eye Relief, mm | 17 |
| Exit Pupil, mm | 4.0-1.3 |
| Minimum Focus Distance, ft | 16.4 |
| Diopter Correction, dpt | +5.0 |
| Light Transmission | 86% |
| Objective Filter Thread | M 82 x 0.75 |
| Viewing Angle | Angled |
| Waterproof, ft/m | 13 / 4 water depth (inert gas filling) |
| Functional Temperature, °F | -4 to +131 |
| Storage Temperature, °F | -22 to +158 |
| Length, in | 15.8" |
| Weight, oz | 57.8 |
