- Battery Illuminated-Powered by a single AA battery, the electronics offer an outstanding level of reliability with a straightforward brightness dial
- Rugged Aluminum-Alloy HousingForged 7075-T6 aircraft-aluminum-alloy housing provides for a nearly indestructible sighting system
- Both Eyes Open Design.The ACOG can be used as a CQB sight when shooting both eyes open utilizing the Bindon Aiming Concept
- Superior Quality Glass Lenses. Multi-coated lenses provide superior clarity and light gathering capabilities with zero distortion
- Fixed Magnifcation
- Combat Proven - No other magnified optic has been used more in combat than the ACOG
- Shock-Resistant -Proven to withstand recoil from a .22LR to a .50BMG and everything in between. Easily passes U.S. Military drop test requirements
- Waterproof to 100 Meters (328ft)Dry-nitrogen filled to eliminate fogging. Five times more waterproof than military standard requirements
- Tritium lamp is warrantied to illuminate for 15 years on fiber optic scopes and 10 years on non-fiber optic scopes
Warranty Information
| Magnification | 4x |
| Objective Size, mm | 32 |
| Field of View (FOV) @ 100yds, ft | 36.8 |
| Field of View, deg | 7° |
| Exit Pupil, mm | 8 |
| Eye Relief, in | 1.5" |
| Bullet Drop Compensator | Yes |
| Illumination Source | LED |
| Reticle Pattern | Crosshair |
| Day Reticle Color | Green |
| Night Reticle Color | Green |
| Calibration | 0.223 |
| Bindon Aiming Concept | Yes |
| Adjustment @ 100 yds, clicks/in | 2 |
| Housing Material | Forged Aluminum |
| Mount Comes With | TA51 |
| Batteries | Single AA Lithium or Alkaline Battery |
| Battery Life | Over 12,000 Hours on Setting #4 Using Supplied Alkaline Battery at 21° C (70° F) |
| Length, in | 6" |
| Weight (With TA51 Mount and Alkaline Battery), oz | 18.1 |
