- Easy adjust side buttons
- 68 MOA Circle Reticle with 1 MOA Dots
- Adjustable, locking quick-detach lever fits both 1" Weaver and MIL-STD-1913 rail
- Operates on 2 common AA Alkaline or Lithium batteries
Warranty Information
| Operation | |
| Optics | Transmission holography |
| Magnification | 1x |
| Eye Relief | Unlimited |
| Size (L x W x H), in | 5.6" x 2.2" x 2.9" |
| Weight, | 13.8 |
| Water Resistant | Submersible to 10 ft (3m) |
| Sealing | Fog resistant internal optics |
| Color/Finish | Non-reflective black |
| Adjustment (per Click), in @ 100yds | 1/2" (0.5 MOA) |
| Adjustment Range | +/- 40 MOA travel |
| Mount | 1" Weaver or MIL-STD 1913 rail |
| Display Window | |
| Optical Surfaces | Anti-Reflection coating on external surfaces |
| Window Dimensions, in. | 1.20" x 0.85" |
| Front Window Material | Glass 1/8" (3.17mm) thick |
| Rear Window Material | Laminate 3/16" (4.76mm) thick |
| Field of View 100 yds | 30 yds (28m) at a 3" eye relief |
| Reticle Options | 68 MOA Ring/1 MOA dot |
| Electrical | |
| Power Source | Two (2) 1.5V x AA batteries |
| Battery Life | 1,000 hrs (lithium) at nominal setting 12; 600 hrs with AA (alkaline) |
| Brightness Settings | 20 settings with scrolling feature |
| Auto Battery Check Indicator | Flashing reticle upon start-up |
| Auto Shut-down | At 8 hrs- programmable to 4 hrs |
